ScrollView

Scrollable container with inertia, elastic bounds, and optional scrollbar handles. Automatically manages a content child that can be a Column, Row, or manual layout.

Inspector Setup

Add AutoLayout to a container GameObject.
Add AutoLayout Scroll View to the same GameObject.
Content child is created automatically. Children added to the scroll view are reparented to the content container.
Optionally assign scrollbar handle RectTransforms.

Field	Type	Default	Description
Scroll Sensitivity	float	20	Mouse wheel multiplier
Scroll Wheel Axis	int	1	0 = horizontal, 1 = vertical
Enable Inertia	bool	true	Momentum after drag
Enable Elastic Bounds	bool	true	Bounce at edges
Deceleration Rate	float	0.135	Inertia decay (0.01-0.5)
Elasticity Duration	float	0.3	Bounce duration
Snap Enabled	bool	false	Enable snap-to-interval after scroll ends
Snap Interval	float	0	Snap interval in pixels (0 = viewport size = page snap)
Snap Alignment	ScrollSnapAlignment	Start	Start or Center alignment within interval
Snap Speed	float	400	Snap animation duration in ms
Vertical Scrollbar Handle	RectTransform	-	Optional vertical scrollbar thumb
Horizontal Scrollbar Handle	RectTransform	-	Optional horizontal scrollbar thumb

Code Usage

AutoUI Builder

// Vertical scroll view (Column content)
AutoUI.Create()
    .WidthFill().HeightFill()
    .ScrollViewVertical()
    .Children(
        AutoUI.Create().WidthFill().Height(100).Background(Color.red),
        AutoUI.Create().WidthFill().Height(100).Background(Color.green),
        AutoUI.Create().WidthFill().Height(100).Background(Color.blue)
        // ... many children
    )
    .Build();

// Horizontal scroll view
AutoUI.Create()
    .WidthFill().Height(200)
    .ScrollViewHorizontal()
    .Children(
        AutoUI.Create().Width(200).HeightFill().Background(Color.red),
        AutoUI.Create().Width(200).HeightFill().Background(Color.green)
    )
    .Build();

AutoUI.ScrollView() (static) is also available as a shortcut for AutoUI.Create().ScrollViewVertical().

Configuring ScrollView

AutoUI.Create()
    .WidthFill().HeightFill()
    .ScrollView(sv =>
    {
        sv.ScrollSensitivity = 30f;
        sv.EnableInertia = true;
        sv.EnableElasticBounds = true;
        sv.DecelerationRate = 0.1f;
    })
    .Children(/* ... */)
    .Build();

Page Snap

AutoUI.Create()
    .WidthFill().HeightFill()
    .ScrollView(sv =>
    {
        sv.SnapEnabled = true;
        // SnapInterval = 0 means page snap (viewport size)
    })
    .Children(
        AutoUI.Create().WidthFill().HeightFill().Background(Color.red),
        AutoUI.Create().WidthFill().HeightFill().Background(Color.green),
        AutoUI.Create().WidthFill().HeightFill().Background(Color.blue)
    )
    .Build();

// Custom interval snap (every 100px)
AutoUI.Create()
    .WidthFill().HeightFill()
    .ScrollView(sv =>
    {
        sv.SnapEnabled = true;
        sv.SnapInterval = 100f;
        sv.SnapAlignment = ScrollSnapAlignment.Center;
        sv.SnapSpeed = 300f;
    })
    .Children(/* ... */)
    .Build();

Programmatic Scrolling

var scrollView = go.GetComponent<AutoLayoutScrollView>();

// Scroll to position
scrollView.ScrollTo(new Vector2(0, 500), animated: true);
scrollView.ScrollTo(500f, animated: true);  // Single axis

// Scroll by delta
scrollView.ScrollBy(new Vector2(0, 100));

// Scroll to child
scrollView.ScrollToChild(childTransform, animated: true);

// Stop scrolling
scrollView.StopScrolling();

// Refresh content size after adding/removing children
scrollView.RefreshContentSize();

Methods

Method	Description
`ScrollTo(Vector2 position, bool animated = true)`	Scroll to absolute position
`ScrollTo(float position, bool animated = true)`	Scroll single axis
`ScrollBy(Vector2 delta)`	Scroll by relative delta
`ScrollBy(float delta)`	Scroll single axis by delta
`ScrollToChild(Transform child, bool animated = true)`	Scroll to make child visible
`RefreshContentSize()`	Recalculate content dimensions
`StopScrolling()`	Stop inertia/animation
`ExcludeFromReparenting(Transform child)`	Prevent child from being reparented to content

Properties

Property	Type	Description
`Content`	RectTransform	Auto-managed content container
`ContentMode`	ScrollContentMode	Column, Row, or Manual
`ScrollOffset`	Vector2	Current 2D scroll offset
`IsScrolling`	bool	Scroll in progress
`IsDragging`	bool	User is dragging
`CanScrollHorizontal`	bool	Content wider than viewport
`CanScrollVertical`	bool	Content taller than viewport
`ScrollSensitivity`	float	Mouse wheel multiplier
`EnableInertia`	bool	Momentum after drag
`EnableElasticBounds`	bool	Edge bounce
`DecelerationRate`	float	Inertia decay rate
`ElasticityDuration`	float	Bounce animation duration
`Physics`	ScrollPhysics	Physics simulation instance
`SnapEnabled`	bool	Snap-to-interval enabled
`SnapInterval`	float	Snap interval (0 = page)
`SnapAlignment`	ScrollSnapAlignment	Start or Center
`SnapSpeed`	float	Snap duration in ms
`IsSnapping`	bool	Snap animation in progress
`Controller`	ScrollController	Headless controller

Content Modes

Mode	Description
`Column`	Content arranged vertically (default for vertical scroll)
`Row`	Content arranged horizontally (default for horizontal scroll)
`Manual`	Custom content layout

Notes

Children added to the scroll view are automatically reparented to the content container.
Use ExcludeFromReparenting() for children that should stay as direct children (e.g., scrollbar overlays).
The scroll view integrates with IUGUILayoutDependent to refresh content size after layout.
Implements IScrollHandler, IBeginDragHandler, IDragHandler, IEndDragHandler.
Scrollbar handles auto-resize based on content-to-viewport ratio.
